Doypack Packaging Machine

Home > Products > Premade Pouch Doypack Packing Machine > Doypack Packaging Machine > Economic Liquid Filling And Sealing Machine Mini Doypack Pouch Packing Machine

Economic Liquid Filling And Sealing Machine Mini Doypack Pouch Packing Machine

Introduction:

This doypack filling and sealing machine is suitable for liquid filling product such as laundry detergent, lubricant, chili sauce, chutney, bean paste,  ketchup, paste, honey, cream, milk, butter, water, olive oil, liquid seasoning, shampoo, etc.


Kindly Reminder:
Please tell us the following information while you send us inquiry. Base on your message, we will suggest the optimum solution to you for reference. Thank you.
1.Your product
2.Packaging Container
3.Output capacity

Benefits & Features
Technical Parameters

VIDEOS

Application

This doypack filling and sealing machine is suitable for liquid filling product such as laundry detergent, lubricant, chili sauce, chutney, bean paste,  ketchup, paste, honey, cream, milk, butter, water, olive oil, liquid seasoning, shampoo, etc.

Economic Liquid Filling And Sealing Machine Mini Doypack Pouch Packing Machine

FEATURES

1. The machine automatically packs/opens bags, with a packing speed of 8-10 packs/min, 600 packs per hour.

2. Single-screw liquid pump, driven by servo motor, can accurately measure 900ml to 3000ml of laundry detergent.

3. The machine is suitable for different bag types, and the bag size can be adjusted freely and flexibly.

4. The success rate of bag opening by the machine is 99.8%, and the bag will not be opened, filled or sealed.

5. The whole machine is made of 304 stainless steel, the quality of the machine is wear-resistant and washable, and it can run smoothly for at least 8-10 years.

Economic Lubricant Filling And Sealing Machine Mini Doypack Pouch Packing Machine

WORKFLOW

01

Automatic Pouch Feeding

02

Bag Open

03

Screw Liquid Pump Filling

04

Automatic Liquid Filling

05

Automatic Sealing

06

Products Feeding

PARAMETER

Economic Liquid Filling And Sealing Machine Mini Doypack Pouch Packing MachineType LDB-200 LDB-300LDB-430
Bag MaterialMulti-layer Composite Premade Bag(e.g.: PET/PE)
Premade bag type3-sides sealing bag, stand-up bag
Upgraded Bag Type(Need additional purchase
of functional device)
Gusset Bag, Zipper Bag, box bag
(Need additional purchase of functional device)
Bag size70mm≤W≤150mm80mm≤W≤300mm80mm≤W≤300mm
70mm≤L≤150mm100mm≤L≤300mm100mm≤L≤430mm
Speed0-60 bags/min 0-15 bags/min
Sealing TypeStraight grain, pitch is 1mm (Optional reticulate)
Sealing Width10mm (5-20mm) can be customized
Voltage220V, Single-phase,50/60HZ, 1.2KW
Air Pressure0.65 Mpa
Air ConsumptionStandard machine, no additional function
Body Dimension1770*600*1230mm1770*600*1360mm
Packing Dimension1860*710*1550mm1860*710*1650mm
Export non-fumigation wooden case

Case Studies

I always turn to LANDPACK Penny every time I need a machine. The powder filling line and liquid filling line and tube filling sealing machine of my new factory are all purchased from Penny. They will customize them according to my products and they are very suitable for my Factory and product needs.
