Fully Automatic Granule Packing Machine Snacks Premade Bag Packing Machine Doypack Machine

Application:

Application for candy, nuts, raisins, peanuts, melon seeds, chocolate biscuits.seasonings, and other granular products filling into zipper bags, standing bags, and premade bag.

Kindly Reminder:

Please tell us the following information while you send us inquiry. Base on your message, we will suggest the optimum solution to you for reference. Thank you.
1.Your product
2.Packaging Container
3.Output capacity

Chat Now Send E-mail

Benefits & Features

Technical Parameters

VIDEOS

Application

Application for candy, nuts, raisins, peanuts, melon seeds, chocolate biscuits.seasonings, and other granular products filling into zipper bags, standing bags, and premade bag.

Fully Automatic Granule Packing Machine Snacks Premade Bag Packing Machine Doypack Machine

FEATURES

1.Easy operation. Most of of parameters in 7inch Simens touch screen with multi-language.

2.Accuracy is very good. Dosing by high precision multihead weigher, Japanese technology ensure high precison and guarratee.

3.Full automatic, Feeding, Dosing, Bag Inputting, Sealing. ( Bag can stand up, or with Euro hole, Linked, date of manufacture )

4.Package Film: Lamination Pouch ,PE,Aluminium Pouch, Paper Pouch, Bag type can be Stand bag, zipper bag, flat bag (3 side seal, 4 side seal, bag with punched hole handle, pillow bag etc.).

Automatic Horizontal Premade Pouch Doypack Granule Packing Packaging Machine For Jerky Biltong

WORKFLOW

Granule Material Feeding

Granule Material weighing

Premade Pouch Opening Filling Sealing

Finished Product Output

PARAMETER

Horizontal Premade Pouch Packing Machine
Type	LDSP-160	LDSP-160Y	LDSP-210	LDSP-260
Bag Type	3-side, 4 side sealing bag, Doypack, Box Pouch, Zipper Pouch, Stand Up Pouch, Stand Up Pouch With Hole, Kraft Paper Bag, Side Gusset Bag etc.
Bag Size	110-230mm80-160mm(LW)	70-100mm110-230(LW)	100-210mm/110-320mm（L*W）	100-260mm/110-320mm（L*W）
Filling Range	10g-100g	10g-100g	10g-1kg	10g-3kg
Packing Speed	20-45bags/min(speed is determined	25-50bags/min(speed is determined	20-50bags/min (speed is determined	20-50bags/min (speed is determined
Packing Speed	by the product filling quantity)	by the product filling quantity)	by the product filling quantity)	by the product filling quantity)
Machine weight	800KG	800KG	900KG	1000KG
Total Power	2.0KW	2.0KW	2.0KW	2.0KW
Work Flow	1.Giving bag 2. Pick up the bag(coding) 3.Open the bag up and down 4.Filling
Collocation	Screw metering,screw elevator
Dimensions	1750mm X 1285mm X 1360mm(LWH)		2140mm X 1366mm X 1360mm(LWH)	2140mm X 1366mm X 1360mm(LWH)
