Automatic Tomato Sauce Miso Lqiudi Packing Machine With CIP Cleaning System

Introduction:

Vertical automatic liquid filling machine applies to packing for fluid, paste, facial cream form material in seasoning-package, oil-package, jam-package, sauce-package and also honey, miso, tomato, sweet and sour sauce, chili sauce, etc.

Kindly Reminder:
Please tell us the following information while you send us inquiry. Base on your message, we will suggest the optimum solution to you for reference. Thank you.
1.Your product
2.Packaging Container
3.Output capacity

Chat Now Send E-mail

Benefits & Features

Technical Parameters

VIDEOS

Application

Automatic Tomato Sauce Miso Lqiudi Packing Machine With CIP Cleaning System

FEATURES

1. Efficient and reliable rotor pump serving as a high-performance feeding pump.

2. Durable stainless steel feeding tube ensuring hygienic and corrosion-resistant operation.

3. Innovative pulling film roller for precise and smooth material handling.

4. Accurate level sensor enabling precise sealing of bag length at the desired position.

5. Versatile double drum roller designed for efficient separation of materials.

6. Convenient outlet conveyors for seamless and efficient product transfer.

Automatic Tomato Sauce Miso Lqiudi Packing Machine With CIP Cleaning System

WORKFLOW

Piston Pump: Precisely measures and dispenses the liquid.

Bag Former: Shapes the bag for packaging.

Filling: The liquid is filled into the bag.

Sealing: The bag is securely sealed to maintain freshness.

PARAMETER

Type	LD-420L	LD-520L	LD-720L
Film width	Max.420MM	Max.520MM	Max.720MM
Bag length	80-300MM	80-350MM	180-350MM
Bag width	60-200MM	100-250MM	100-500MM
Film thickness	0.04-0.08 MM	0.04-0.12MM	0.04-0.12MM
Packaging rate	5-60Bag/Min	5-60Bag/Min	5-55Bag/Min
Range of measurement	150-1500ml	2000ml	4000ml
Machine size	121710151343MM	148810801490MM	178013502050MM
Machine quality	650KG	680KG	750KG
Power	220V 50/60Hz 2KW	220V 50/60Hz 3KW	220V 3KW
