Automatic Liquid Spout Pouch Packing Machine Horizontal Premade Pouch Doypack Packaging Machine

Introduction:

Suitable for all kinds of liquid products and can pack different premade bags. It is applied to various types of liquid such as liquid detergent, honey, milk, olive oil, ketchup, paste, sauce, fruit juice, chili sauce, sunflower oil, mayonnaise, laundry liquid, etc.

Kindly Reminder:
Please tell us the following information while you send us inquiry. Base on your message, we will suggest the optimum solution to you for reference. Thank you.
1.Your product
2.Packaging Container
3.Output capacity

Chat Now Send E-mail

Benefits & Features

Technical Parameters

VIDEOS

Application

Automatic Liquid Spout Pouch Packing Machine Horizontal Premade Pouch Doypack Packaging Machine

FEATURES

1. Specifically designed for spout bags, ensuring successful automatic bag picking for smooth operation.

2. Two filling nozzles work simultaneously, allowing the total target filling volume to be reached. The individual filling volumes can be adjusted independently, shortening the filling time and increasing packaging speed.

3. Prevents the bag from sliding down due to the heavy filling weight, ensuring accurate sealing without tilting or poor-quality seals.

4. Ensures the bag opens fully and filling is successful.

5. High-quality control system for reliable performance.

6. Handles bags with dimensions of 120-260 mm width and 110-360 mm length.

7. Simple to operate with a high filling accuracy, maintaining an error margin of only 1%.

Automatic Liquid Spout Pouch Packing Machine Horizontal Premade Pouch Doypack Packaging Machine

WORKFLOW

Horizontally bag giving

Automatic taking bag

Ribbon code printing

Open bag up and down

Filling one

Forming

Sealing

Output

PARAMETER

Model	LDSP-160	LDSP-210	LDSP-260
Bag Type	3-side, 4-side sealing bag, Doypack, Box Pouch, Zipper Pouch, Stand Up Pouch, Stand Up Pouch With Hole, Kraft Paper Bag, Side Gusset Bag, etc.
Pouch Size (mm)	110-230mm(L); 80-160mm(W)	70-100mm(L); 110-230mm(W)	100-260mm(L); 110-320mm(W)
Filling Range	10g-100g	10g-1kg	10g-3kg
Packing Speed	20-45 bags/min	20-50 bags/min	20-50 bags/min
Power	2 KW	2 KW	2 KW
Workflow	1. Giving bag; 2. Pick up the bag(coding); 3. Open the bag up and down; 4. Fill; 5. Heating sealing; 6. Output of product
Machine Size	1750mm1285mm1360mm(LWH)	2140mm1366mm1360mm(LWH)
Collocation	Screw metering, screw elevator
Machine Weight	800 kg	900 kg	1000 kg
